The Amerex KP 1x55 Nozzle (P/N 11983) serves dual duty in the Amerex KP Restaurant Fire Suppression System as both the solid-fuel charbroiler nozzle (for charcoal and mesquite appliances) and a duct coverage nozzle, consuming 1.5 flow points per nozzle. Identified by 3 tactile rings. For solid-fuel charbroiler applications, the nozzle is mounted 16 to 42 inches above the cooking surface per the KP design manual. For duct coverage, a single 11983 covers ducts up to 50 perimeter inches; two 11983 nozzles cover ducts up to 100 perimeter inches. Includes a high-temperature cap (P/N 12504) appropriate for solid-fuel appliance environments. Compatible with swivel adapter P/N 16440. For full background on the Amerex KP nozzle family, refer to the 2xR Nozzle product page (P/N 14178).
| Feature | Details |
|---|---|
| Manufacturer | Amerex Corporation |
| Part Number | 11983 |
| Nozzle Designation | 1x55 (Solid Fuel Charbroiler / Duct) |
| Flow Points | 1.5 |
| Tactile Identification | 3 Rings |
| Thread Size | 3/8 Inch NPT |
| Applications | Solid-Fuel Charbroilers (Charcoal/Mesquite) and Exhaust Ducts |
| Charbroiler Mounting Height | 16 to 42 Inches Above Cooking Surface |
| Single Nozzle Duct Coverage | Up to 50 Perimeter Inches |
| Two Nozzle Duct Coverage | Up to 100 Perimeter Inches |
| Nozzle Cap Included | High-Temperature Cap P/N 12504 |
| Swivel Adapter (Optional) | P/N 16440 |
| System | Amerex KP Restaurant Fire Suppression System |
| Certifications | UL Listed (UL 300), NFPA 17A and 96 Compliant |
| Lead Product Page | 2xR Range/Griddle Nozzle P/N 14178 |
