Double Plastic Fire Extinguishers Cabinet For 10LB and 20LB Fire Extinguishers - 25018
Are you a fire protection company? Get wholesale pricing at HedrickPro
Wholesale PricingThe Victory Double Plastic Fire Extinguisher Cabinet (P/N 25018) is a side-by-side dual housing for two 10 lb or 20 lb dry chemical fire extinguishers, designed for indoor and outdoor use. At 28 x 22.8 x 10.6 inches, it provides enough interior space for two standard dry chemical units in the 10 lb to 20 lb range while keeping both protected, visible, and accessible in a single compact footprint. The extinguishers themselves are not included.
Made from heavy-duty plastic, the cabinet resists the rust and corrosion that can affect painted steel enclosures in outdoor, humid, or coastal environments. A door with a buckle lock keeps the units secured against tampering or accidental displacement while still allowing quick access in an emergency. The back panel is perforated to allow wall mounting with screws or nails, which are not included. The cabinet can also be floor mounted where wall mounting is not practical. It is compatible with 10 lb and 20 lb dry chemical extinguishers from major manufacturers, not only Victory brand units.
- Two-Unit Placement Points: Locations where code requires two extinguishers at or near the same spot, such as a loading dock entrance or the end of a large warehouse aisle.
- Outdoor and Exposed Locations: The plastic construction resists weather exposure, making it well suited for outdoor equipment yards, parking structures, and construction sites.
- Space-Efficient Coverage: Consolidating two extinguishers into one housing reduces wall footprint compared to mounting two separate brackets or single-unit cabinets side by side.
- Wall and Floor Mount Options: The perforated back supports both wall and floor-mounted installation depending on the location's requirements.
| Feature | Details |
|---|---|
| Brand | Victory |
| Part Number | 25018 |
| Configuration | Double (Two Extinguishers) |
| Suitable Extinguisher Sizes | 10 LB and 20 LB Dry Chemical ABC |
| Dimensions | 28 x 22.8 x 10.6 Inches |
| Material | Heavy-Duty Plastic |
| Closure | Door with Buckle Lock |
| Mounting | Wall Mount or Floor Mount (Screws and Nails Not Included) |
| Use Environment | Indoor and Outdoor |
| Extinguishers Included | No |
- Mounting Height: Per NFPA 10, extinguishers with a gross weight of 40 lbs or less must be installed so the top is no more than 5 feet above the floor. Mount the cabinet so both housed extinguishers remain within this height range.
- Visibility: The cabinet must be clearly visible or marked with a sign, per NFPA 10.
- Monthly Visual Inspection: Confirm the door and buckle lock are intact, both extinguishers are properly seated inside, and the pressure gauges on both units are in the green zone as part of the routine NFPA 10 monthly inspection.
Will this fit two 5 lb extinguishers?
The cabinet is sized for 10 lb and 20 lb units. Smaller 5 lb extinguishers will fit physically but will have more interior space than necessary, which may allow them to shift inside the cabinet. Victory's single-unit cabinet in the 10 lb size is a better fit for smaller units.
Does this work with extinguisher brands other than Victory?
Yes. The cabinet fits standard 10 lb and 20 lb dry chemical extinguishers from major manufacturers and is not limited to Victory brand units.
Is this fire-rated for installation in a fire-rated wall?
No. This is a surface-mounted plastic cabinet for general indoor and outdoor use. It is not certified for installation in a fire-rated wall assembly, which requires a Warnock-Hersey approved metal cabinet.
